Ranger 80 White Large

Precision-made Portable HF Antenna System

Benefits

Rugged Construction

CNC machined from premium materials. A Delrin body, black anodized 6061 aluminum and all stainless steel hardware to take on any environment, any time.

easy to use

The Ranger 80 comes fully assembled and includes a premium 3-Day MOLLE backpack to keep everything organized. Just open the package and get right on the air.

Ranger Bag v2.png
Collar Adjust.png

Work 80-15m

Designed for use on the ham radio bands, the Ranger's adjustable coil allows for fine tuning from 80-15m with the included military whip. Add 12-10m by purchasing the light- duty telescoping whip.

Lightning Fast Setup

Thanks to our quick-deploy radial system, you'll be making contacts in no time.

Now available at

videos

REZ Antennas New Universal ZQD Radial Puck For WRC Antennas
06:27

REZ Antennas New Universal ZQD Radial Puck For WRC Antennas

Quick And Easy! Modify Your Wolf River Coils Antenna For Faster Setup With The REZ Universal [Z]QD Radial Puck! Get it here: https://www.rezantenna.com/product-page/universal-puck (non affiliate) Banana Plug: https://amzn.to/3p547jI Consider becoming a Patron @ https://www.patreon.com/k8mrdradiostuff Follow me on Twitter. https://twitter.com/k8mrd Links to many of the things I use can be found here: https://www.amazon.com/shop/k8mrdradiostuff As an Amazon Associate I earn from qualifying purchases. Big Geek Battery Box, https://k8mrd.square.site Watch the video here: https://youtu.be/OzkQ7Xd_QHs Tri-Lam BuddiStick Pro Counterpoise Support: https://k8mrd.square.site K8MRD Radio Stuff Shirts: Happy Skull Guy: https://grapevineamateurradio.com/collections/youtubers-bunch/products/k8mrd-radio-stuff-t-shirt-special-order Tower of Terror: https://grapevineamateurradio.com/collections/youtubers-bunch/products/k8mrd-radio-stuff-tower-t-shirt-special-order Parks On The Air Merch (non affiliate) https://www.clubgearonline.com Links to other stuff (affiliate where possible) **Save 15% off your Coax order at ABR Industries. Use code K8MRD at checkout. https://abrind.com The SkyHook Portable Mast Antenna Mount (non affiliate) http://www.thehamstop.com/ Use code K8MRDRADIO for 20% off Save 5% Off At Gigaparts With Code K8MRD: https://www.gigaparts.com/nsearch/?lp=Mike%20K8MRD%20Page#?lp=Mike+K8MRD+Page&Stockstatusfilter=Currently+in+stock%21&search_return=all&res_per_page=60 5% off Messi & Paoloni Coax Use code K8MRD for 5% off. https://messi.it. (or you can order from Gigaparts) Signal Stuff Signal Stick Antennas: BNC Antenna: https://signalstuff.com/super-elastic-signal-stick-bnc/?ref=4089 SMA Female Antenna: https://signalstuff.com/super-elastic-signal-stick-sma-female/?ref=4089 SMA Male Antenna: https://signalstuff.com/super-elastic-signal-stick-sma-male/?ref=4 Signalstuff Antennas: https://signalstuff.com/?ref=4089 ~~~$15 off most purchases over $65 at Radioddity: http://radioddity.refr.cc/mikedahlhofer #hamradio #REZAntennas #WolfRiverCoils
REZ Antenna Systems Ranger 80 Vertical Ham Radio Antenna
13:15

REZ Antenna Systems Ranger 80 Vertical Ham Radio Antenna

Digital, SSB, CW, The Ranger 80 From REZ Antenna Systems Does It All. Let's Put It To The Test! https://www.rezantenna.com Consider becoming a Patron @ https://www.patreon.com/k8mrdradiostuff Follow me on Twitter. https://twitter.com/k8mrd Links to many of the things I use can be found here: https://www.amazon.com/shop/k8mrdradiostuff As an Amazon Associate I earn from qualifying purchases. Big Geek Battery Box: https://k8mrd.square.site Watch the video here: https://youtu.be/OzkQ7Xd_QHs Tri-Lam BuddiStick Pro Counterpoise Support: https://k8mrd.square.site K8MRD Radio Stuff Shirts: Happy Skull Guy: https://grapevineamateurradio.com/collections/youtubers-bunch/products/k8mrd-radio-stuff-t-shirt-special-order Tower of Terror: https://grapevineamateurradio.com/collections/youtubers-bunch/products/k8mrd-radio-stuff-tower-t-shirt-special-order Links to other stuff (affiliate where possible) **Save 15% off your Coax order at ABR Industries. Use code K8MRD at checkout. https://abrind.com The SkyHook Portable Mast Antenna Mount (non affiliate) http://www.thehamstop.com/ Use code K8MRDRADIO for 20% off Save 5% Off At Gigaparts With Code K8MRD: https://www.gigaparts.com/nsearch/?lp=Mike%20K8MRD%20Page#?lp=Mike+K8MRD+Page&Stockstatusfilter=Currently+in+stock%21&search_return=all&res_per_page=60 Signal Stuff Signal Stick Antennas: BNC Antenna: https://signalstuff.com/super-elastic-signal-stick-bnc/?ref=4089 SMA Female Antenna: https://signalstuff.com/super-elastic-signal-stick-sma-female/?ref=4089 SMA Male Antenna: https://signalstuff.com/super-elastic-signal-stick-sma-male/?ref=4 Signalstuff Antennas: https://signalstuff.com/?ref=4089 ~~~$15 off most purchases over $65 at Radioddity: http://radioddity.refr.cc/mikedahlhofer #hamradio #parksontheair #k8mrd

24-hour real-world performance

MODE: WSPR   POWER:1w  |  BAND: 20m

This test represents the following antenna configuration:

[Z]Pod tripod, 9.3’ military whip, 4 33’ radials, 50 feet RG8X coax, soil conductivity: 30 Millimhos/Meter.

During our 24-hour WSPR test, our 1 watt signal was heard over 3,000 times across Europe, Africa, Hawaii, North America, Central America, South America and reaching as far as 14,934 km to the southern coast of Australia.

Ranger 80 WSPR 1w 20m.png

system Specs

Specs

tuning coil

Stainless wire.png
CNC Delrin.png
Stainless Hardware.png
Power Handling: 200 watts SSB, 100 watts digital (50% duty cycle)

Whip Mount Thread Pitch: 3/8-24

Base Mounting Stud Thread Pitch: 3/8-24


ground spike

Stainless Steel Construction

For Use in Soft to Medium Soils
 (not recommended for hard or rocky soil)

military whip

Background copy.png
7 Tapered Sections
Extended Length: 9.3’

Brass/Stainless Steel Construction



Stealth Black Coating

radial system

Radial Wire Wrapped.png
Banana Plug.png

ranger 80 swr charts

These charts represent the following antenna configuration:

[Z]Pod tripod, 9.3’ military whip, 4 33’ radials, 50 feet RG8X coax.

Note: The resonant point of this antenna is adjustable. These sweeps were ran with the antenna tuned to roughly the middle of each band for illustrative purposes.

15 meters

15m Scan.png

Minimum SWR: 1.5 at 21 MHz

2:1 SWR Bandwidth: 3.185 MHz

To achieve better SWR on this band a shorter whip is recommended

20 meters

20m Scan.png

Minimum SWR: 1.14 at 14.20 MHz

2:1 SWR Bandwidth: 1.86 MHz

17 meters

17m Scan.png

Minimum SWR: 1.3 at 18.12 MHz

2:1 SWR Bandwidth: 3.25 MHz

40 meters

40m Scan.png

Minimum SWR: 1.04 at 7.159 MHz

2:1 SWR Bandwidth: 355.5 kHz

80 meters

80m Scan.png

Minimum SWR: 1.46 at 3.757 MHz

2:1 SWR Bandwidth: 67 kHz
